The Leeb Coating Thickness Gauge series offers comprehensive coating measurement solutions utilizing both magnetic induction and eddy current technologies. The devices feature high precision measurement capabilities with ranges up to 1250μm and accuracy of ±[(1-3%)H+1]. Operating through an English menu interface, these gauges provide dual working patterns (direct and group modes) and incorporate real-time battery monitoring. The systems deliver precise measurements with 0.1μm resolution and can operate effectively on curved surfaces with minimum convex radius of 1.5mm and concave radius of 9mm.
Built for professional field use, the series features robust data management capabilities storing up to 500 measurements with comprehensive statistical analysis including mean value, maximum, minimum, and standard deviation calculations. The devices include advanced calibration options with basic and system error correction methods, along with limit setting capabilities for quality control applications. Powered by AAA alkaline batteries, these compact units (150×55.5×23mm) operate efficiently in temperatures from 0°C to 40°C with 20-90% humidity tolerance. Each unit comes complete with a probe matrix and five calibration specimens (50mm-1000mm).
Applications
– Hull coating inspection
– Oil and gas pipeline measurement
– High-pressure vessel testing
– Boiler wall thickness assessment
– Non-magnetic coating verification
– Quality control inspection
– Industrial coating measurement
– Metallic substrate testing
